iiyama 24/7 interaktív kijelző, 54,6" 3840 x 2160 , 16:9, 500cd, 8ms, 1200:1, HDMIx2/DP/USBx2/RS-232C/RJ45

Ugrás a termék információkhoz
iiyama 24/7 interaktív kijelző, 54,6 iiyama 24/7 interaktív kijelző, 54,6 iiyama 24/7 interaktív kijelző, 54,6 iiyama 24/7 interaktív kijelző, 54,6 iiyama 24/7 interaktív kijelző, 54,6
iiyama 24/7 interaktív kijelző, 54,6
iiyama 24/7 interaktív kijelző, 54,6
iiyama 24/7 interaktív kijelző, 54,6
iiyama 24/7 interaktív kijelző, 54,6
iiyama 24/7 interaktív kijelző, 54,6

Paraméterek

Display Port Van
Érintőképernyő (Igen/Nem) Van
Ethernet, LAN (RJ-45) port 1
Fali rögzítés 400x400mm VESA falitartó-támogatás
Felbontás 3840 x 2160 (UHD)
Fényerő 500
Gyártó IIYAMA
Hangszóró Van
HDMI Van
Képátló 54.6
Kontrasztarány 1200
Panel típus IPS
Üzemidő 24/7
USB Van
966.290 Ft (760.858 Ft + ÁFA)
Menny.: db
Értesítés
Gyors szállítás
Válogatott raktárkészlet
Segítünk, ha kérdésed van

Leírás

Vélemények

Erről a termékről még nem érkezett vélemény... Legyél Te az első!
Írj véleményt!

Leírás és Paraméterek

  ProLite TF5539AS-B1AG

DISPLAY CHARACTERISTICS
Design Edge to edge glass, Open Frame
Diagonal 54.6", 139cm
Panel IPS LED, AG coated glass, matte finish
Native resolution 3840 x 2160 @60Hz (8.3 megapixel 4K UHD)
Aspect ratio 16:9
Panel brightness 500 cd/m²
Brightness 435 cd/m² with touch
Light transmittance 87%
Static contrast 1200:1
Response time (GTG) 8ms
Viewing zone horizontal/vertical: 178°/178°, right/left: 89°/89°, up/down: 89°/89°
Colour support 1.07G (8 Bits+FRC) (72% NTSC)
Horizontal Sync 28 - 160kHz
Viewable area W x H 1209.6 x 680.4mm, 47.6 x 26.8"
Bezel width (sides, top, bottom) 30mm, 30mm, 30mm
Pixel pitch 0.315mm
Bezel colour and finish black, matte

TOUCH
Touch technology bonded PCAP
Touch points 40
Touch accuracy +- 2.5mm
Touch method stylus, finger, glove (latex)
Touch interface USB
Supported operating systems All iiyama monitors are Plug & Play and compatible with Windows and Linux. For details regarding the supported OS for the touch models, please refer to the driver instruction file available in the downloads section.
Through-Glass 6mm
Palm rejection yes

INTERFACES / CONNECTORS / CONTROLS
Digital signal input HDMI x2 (2.0, max. 3840x2160 @60Hz)
DisplayPort x1 (1.2, max. 3840x2160 @60Hz)
Monitor control input RS-232c x1 (Get/Set Command)
RJ45 (LAN) x1 (Control and Internet)
Audio output Mini jack x1
Speakers 2 x 10W
HDCP 2,2
USB ports x2 (2.0 x2 (Type A))

FEATURES
Integrated software Android 11 OS, iiSignage², EShare, FailOver
Hardware CPU: A73*4+A53*4, GPU: G52 MP8, RAM: 4GB, ROM: 32GB
Extra handles, Touch Through-Glass
Kiosk mode yes
Max. non-stop operating time 24/7
Anti image retention yes
Glass thickness 4mm
Glass hardness 7H
60950 Ball drop test yes
Water and dust protection IP65 (front)
Housing (bezel) metal
OSD key lock yes
Remote control lock yes

GENERAL
OSD languages EN, DE, FR, ES, IT, RU, CZ, NL, PL, SV, FI, DA, NB
Control buttons Power
User controls picture (brightness, contrast, sharpness, back level, tint, colour, noise reduction, gamma selection, low blue light, colour temp., colour control, overscan, picture reset), screen (zoom mode, custom zoom, screen reset), audio (balance, treble, bass, volume, audio out (line out), max. volume, min. volume, mute, audio reset, audio out sync, speaker setting), configuration 1 (Android launcher, switch on state, Touch lock, Touch mode, mouse mode, panel saving, RS232 routing, boot on source, WOL, conf.1 reset, factory reset), configuration 2 (OSD timeout, OSD H position, OSD V position, system rotation, info OSD, logo and animation, logo setting, animation setting, monitor ID, monitor info, HDMI version, conf. 2 reset), advanced options (kiosk mode, side bar, no signal image, motorized stand, IR control, power LED light, fan, off timer, schedule, HDMI with one wire, HDMI with one wire off, failover, language, OSD transparency, power saving, advanced options reset)
Plug&Play DDC2B

MECHANICAL
Orientation landscape, portrait, face-up
VESA mounting 400 x 400mm
Mini PC mount VESA 100 x 100, NUC INTEL
Operation temperature range 0°C - 40°C
Storage temperature range - 20°C - 60°C
MTBF 50000 hours (excluding backlight)

ACCESSORIES INCLUDED
Cables power (1.8m), USB (1.8m), HDMI (1.8m), DP (1.8m)
Guides quick start guide, safety guide
Cable cover yes
